Scribe Insight – Using DBLOOKUP formula to set Lookup in Dynamics 365 CE

dblookup-main

In this article, we will learn how to setup lookups using DBLOOKUP formula of Scribe Insight.

The basic example we will be taking is to set parent contact id (customerid) field of Opportunity entity.

For the source, we will be using SQL Server Database, and to keep it simple we are populating only 2 fields here Topic and Contact of the opportunity entity record.

Contact column will be used for setting the lookup field in the Opportunity.

Here is our source SQL Table

sql-table

Open Scribe Workbench and create a new Microsoft SQL Server connection as source.

sql-table

Select the Opportunity source table created.

sql-table

Next, click on Configure Steps and add Microsoft Dynamics 365 customer services and CRM connection. Create a new connection if not already created.

Select Opportunity entity and for operation select Insert and click on Add Insert Step.

sql-table

Click on Close.

Now let us define the mapping

Select Topic field from the source and select name field of the contact entity in the destination and click on Data Link

sql-table

Next select Contact from the source and select customerid from the destination and click on Lookup Link

sql-table

Next, click on Formula to define the DBLookup formula

DBLOOKUP Formula

DBLOOKUP( TextSourceField, "connection", "table", "lookup_field", "substitution_field" )

Specify the formula as shown below.

Here we are doing the lookup based on the fullname field of contact entity and we can contact’s GUID to be returned.

sql-table

Click on OK to close the window.

Next, select customeridtype field and specify the value as contact for it.

sql-table

Save the package and Click on the Run icon to run the package

sql-table

We can see 2 records processed successfully.

sql-table

Inside Dynamics 365 we can see 2 Opportunity records created with customer id field set properly.

sql-table

Thus we saw how easy it is to set Lookups using DBLOOKUP formula in Scribe Insight.

<
